| Medidas |
KG/M |
Sección en mm.
h |
Sección en mm.
b |
Sección en mm.
e |
Sección en mm.
e1 |
| 100 |
42,85 |
120 |
106 |
12,0 |
20,0 |
| 120 |
53,40 |
140 |
126 |
12,5 |
21,0 |
| 140 |
64,78 |
160 |
146 |
13,0 |
22,0 |
| 160 |
78,11 |
180 |
166 |
14,0 |
23,0 |
| 180 |
91,12 |
200 |
186 |
14,5 |
24,0 |
| 200 |
105,58 |
220 |
206 |
15,0 |
25,0 |
| 220 |
119,93 |
240 |
226 |
15,5 |
26,0 |
| 240 |
160,93 |
270 |
248 |
18,0 |
32,0 |
| 260 |
176,30 |
290 |
268 |
18,0 |
32,5 |
| 280 |
193,73 |
310 |
288 |
18,5 |
33,0 |
| 300 |
243,95 |
340 |
310 |
21,0 |
39,0 |
| 320 |
251,13 |
359 |
309 |
21,0 |
40,0 |
| 340 |
254,20 |
377 |
309 |
21,0 |
40,0 |
| 360 |
256,25 |
395 |
308 |
21,0 |
40,0 |
| 400 |
262,40 |
432 |
307 |
21,0 |
40,0 |
| 450 |
269,58 |
478 |
307 |
21,0 |
40,0 |
| 500 |
276,75 |
524 |
306 |
21,0 |
40,0 |
| 550 |
284,95 |
572 |
306 |
21,0 |
40,0 |
| 600 |
292,13 |
620 |
305 |
21,0 |
40,0 |
| 650 |
300,33 |
668 |
305 |
21,0 |
40,0 |
| 700 |
308,53 |
716 |
304 |
21,0 |
40,0 |
| 800 |
324,93 |
814 |
303 |
21,0 |
40,0 |
| 900 |
341,33 |
910 |
302 |
21,0 |
40,0 |
| 1000 |
357,73 |
1008 |
302 |
21,0 |
40,0 |
|
